KSA Industrial Automation Company integrates Elcontrol energy monitoring software in Saudi Arabia, connecting NanoVIP analysers and Energy Studio to PLCs and SCADA over Modbus. Elcontrol is our authorised Italian technology partner. We configure the meters, map the registers, build the dashboards and prove the readings against a calibrated reference on your site.
What you receive: a written proposal with the meter list, network plan, register map, dashboards and programme, issued within one working day of receiving your single-line diagram or meter schedule. Request a quotation
Elcontrol energy monitoring software and what it connects
Elcontrol is an Italian maker of energy analysers, controllers and software. Its NanoVIP analysers measure voltage, current, power and energy, and report them on an RS485 Modbus line. The Energy Studio software collects the readings from many meters and presents them as trends and reports. We link the two to the control layer, so energy becomes another signal in the plant.
| Item | What we do | Standard / protocol | Typical duration |
|---|---|---|---|
| Meter configuration | NanoVIP addresses, CT ratios and communication settings | Modbus RTU | Per meter count |
| Network design | RS485 line planning, termination and gateways to Ethernet | Modbus TCP gateway | Per project schedule |
| Energy Studio set-up | Meter groups, tariff periods, trends and reports | Elcontrol software | Per project schedule |
| PLC and SCADA link | Register mapping into controllers and supervisory screens | Modbus, OPC UA | 3–8 weeks including telemetry links |
| Verification | Readings compared with a reference instrument; signed record | Your ITP or ours | Per project schedule |
How do Elcontrol analysers connect over Modbus to SCADA?
Each NanoVIP carries a Modbus address and sits on an RS485 daisy-chain. A gateway or a PLC serial port polls the chain, and the SCADA reads the values from that master over Modbus TCP or OPC UA. The common faults are duplicate addresses, wrong parity settings, missing termination and mismatched CT ratios, so we check all four during commissioning.
We document the register map in a form your own technicians can read, with scaling and units for every value. You can then add a meter later without calling us. Where the plant has a historian, we write the energy values to it with the same tag names used on the screens.
Is Elcontrol Energy Studio free?
Licence terms are set by Elcontrol, and they vary by edition and number of meters, so we confirm what your site holds before design starts. In either case our scope is the same: installation, configuration of meter groups and tariffs, report layouts and user access. We deliver a configuration backup so that a replacement PC can be restored quickly.
If you prefer your own SCADA for dashboards, we can bypass the software and read the meters directly. The choice depends on how many meters you have and who maintains the system afterwards.
Can Elcontrol meters feed a PLC?
Yes. A PLC with a serial port or a Modbus gateway can read the analysers at a fixed scan time, and the values then drive alarms, interlocks and load-shedding logic. We also use the readings for simple tasks such as an alarm when a motor draws more than its normal current. Our wider energy monitoring systems work places these readings in plant-wide reports by line and shift.
How do we deliver an energy monitoring integration?
- Enquiry. You send the single-line diagram, the list of meters and the network layout of the plant.
- Survey. We confirm meter locations, CT sizes, cable routes and the protocol each device speaks.
- Design. We issue a network diagram, address plan and register map for approval.
- Configuration. Meters, gateways and Energy Studio are set up to the approved plan.
- Integration. Values are mapped to the PLC or SCADA, with alarms and trends added.
- Verification. Readings are compared with a reference instrument and each result is recorded.
- Documentation and support. You receive the register map, configuration backups and a short operator guide.
Where we integrate Elcontrol equipment
Our engineers have worked on Saudi plants since 1995 and hold approval from Saudi Aramco, SABIC and the Royal Commission for Jubail and Yanbu. We have worked on projects for Marafiq in Jubail.
Energy monitoring suits plants that bill internal departments, track compressed air or chilled water cost, or need evidence of savings. Industrial cities in the Eastern Province, such as Dammam and Jubail, are within a day's reach of our Dammam office, and we take projects across Saudi Arabia. Read more about SCADA integration for the supervisory layer.
Elcontrol partner questions
Who provides Elcontrol energy monitoring software integration in Saudi Arabia?
KSA Industrial Automation Company provides Elcontrol energy monitoring software integration in Saudi Arabia from its Dammam engineering office. We configure NanoVIP analysers and Energy Studio, link them to PLCs and SCADA over Modbus, and verify the readings on your site.
Can Elcontrol meters feed a PLC or a SCADA system?
KSA Industrial Automation Company provides that link as standard work. A PLC or Modbus gateway polls the NanoVIP chain, and the SCADA reads the values over Modbus TCP or OPC UA. We agree the register map first, so scaling and units are correct on every screen.
What affects the cost of Elcontrol energy monitoring integration?
The meter count, the distance and layout of the RS485 network, the number of gateways, the dashboards and reports required, and any link to a historian or PLC all affect the price. Send the meter schedule and a plant layout, and the proposal prices each of these items.
How long does an energy monitoring integration take?
Projects that include telemetry links usually take three to eight weeks. A small group of meters on one panel takes less time. Cable routes, shutdown windows for CT installation and the speed of approvals decide the final schedule, and we state it in the proposal.
What do you configure in Energy Studio Manager?
We configure the plant structure, meter groups, tariff periods, report schedules and user access, then save the configuration to a file. Available features depend on the edition your site holds, so we confirm the version first. You receive the backup file, which lets a replacement PC be restored quickly.
What should I send to get a quotation?
Send the single-line diagram, a list of the meters or the points to be measured, the CT ratios if known and the plant network layout. If you already use Elcontrol equipment, add the model numbers and the software version.
Need Elcontrol energy monitoring software integration in Saudi Arabia? Email the meter schedule and single-line diagram, and our proposal follows within one working day. See every automation partner.
